14mm Canon EF MKI T2.9

Common focus and iris gear positions relative to mount flange, same as K35's
New circular iris design
Less than 9" minimum object distance.
110mm common front ring diameter.
PL mount; back focus adjustable with standard shims.
Price: POA (Price On Application)

14mm Canon EF MKI T2.9 Specification

	10mm	14mm	18mm FD-X	20mm	24mm	28mm	35mm	35mm FD-X	45mm FD-X	50mm	55mm	70mm FD-X	85mm	100mm	135mm	200mm
Mount	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL	PL
T-Stop	2.9	2.9	1.6	2.9	1.5	2.1	2.1	1.5	1.5	1.3	1.3	1.3	1.3	2.1	2.1	2.9
Min. Object Distance typ.	7"	8"	10"	10"	12"	12"	12"	12"	13"	18"	2'	2'3"	3'	2'2"	3'8"	4'7"
Front Diameter	125mm	110mm	143mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm	110mm
Total Length*	88mm	75mm	100mm	69mm	80mm	80mm	90mm	90mm	69mm	83mm	73mm	125mm	94mm	98mm	119mm	130mm
Total Length*	3.5"	3.0"	3.9"	2.7"	3"	3.1"	3.5"	3.5"	2.7"	3.3"	2.9"	4.2"	3.7"	3.9"	4.7"	5.1"
Weight**	TBC	1.3kg	TBC	1.1kg	1.3kg	1.2kg	1.3kg	1.3kg	0.9kg	1.3kg	TBC	2.12kg	1.7kg	1.5kg	1.67kg	TBC
Weight**	TBC	3lbs	TBC	2lb 7oz	2lb 14oz	2lb 10oz	2lb 14oz	2lb 14oz	1lb 15oz	2lb 14oz	TBC	4lb 11oz	3lb 12oz	3lb 5oz	3lb 13oz	TBC

*Total approximate length is measured from the flange to the front of lens
** Weight subject to change with further developments
TBC - To be confirmed
