Common focus and iris gear positions relative to mount flange.
Close focus of typically 11".
110mm common front ring diameter.
M105 front filter thread.
PL mount; back focus adjustable with standard shims.
Price: POA (Price On Application)
Cam driven focus system and chassis style lens housing allow matte boxes and other accessories to be attached to the front of the lens, without affecting focus movements. The benefit of zero backlash and image shift give accurate dual focus scales that repeat on direction and change with the cam drive system, giving a wide spread of markings through the scale.
Aluminium alloy, stainless steel, brass and robust construction guarantees along serviceable life.
|Min. Object Distance typ.||7"||11"||11"||11"||14"||20"||19'||3'3'|
|Front Diameter (mm)||125mm||110mm||110mm||110mm||110mm||110mm||110mm||110mm|
|Total Length *(mm)||55mm||108mm||141mm||68mm||68mm||68mm||88mm||128mm|
|Total Length *(inches)||2 3/16"||4 1/4"||5 9/16"||2 11/16"||2 11/16"||2 11/16"||3 7/16"||5"|
|Weight **(lbs)||2lbs 3oz||3lbs 9oz||4lbs 7oz||2lbs 6oz||2lbs 3oz||3lbs 4oz||3lbs||4lbs 1oz|
* Total approximate length is measured from the flange to the front of lens
** Weight subject to change with further developments
